The CG108-12 High Voltage Insulator Capacitive Sensor is a precision device designed for accurate voltage monitoring in medium-voltage and high-voltage switchgear systems. Featuring advanced capacitive sensing technology and robust epoxy resin insulation, the CG108-12 ensures reliable, long-term operation, enabling utilities, industrial facilities, and power engineers to monitor electrical networks safely and efficiently.

Its design emphasizes environmental sustainability, durability, and compatibility with modern smart grid systems. The sensor’s high accuracy and low maintenance requirements make it an ideal choice for both indoor and outdoor switchgear applications.
